Product Description
Racer CC– Advanced Platform for Redefining Flexibility in tortuous anatomy
- Racer CC is a Biodegradable Polymer Coronary Drug Eluting Stent. The Drug is Sirolimus which is a well-studied and clinically proven immunosuppressant.
- The Stent platform is of Cobalt Chromium with Microporous Stent Surface. The patented technology of micro pores acts like reservoirs for delivering the drug to the targeted site. Micro pores use vander-wall forces for the controlled released of drug. Microporous surface also reduce the polymer load to 1/4th.
- The Dual drug matrix is coated on the Abluminal side which ensures better Endothelialization and less systemic exposure of the drug.
- Shellac Resin is the top coat of the stent for smooth surface which prevents dual drug matrix break ups during stent expansion.
Product Matrix/ Ordering Information
| Stent Diameter Ø (mm) | Stent length (mm) & Article number | |||||||
| 8 | 12 | 16 | 18 | 21 | 24 | 28 | 32 | |
| Ø2.00 | RRCC2008 | RRCC2012 | RRCC2016 | RRCC2018 | RRCC2021 | RRCC2024 | RRCC2088 | RRCC2032 |
| Ø2.50 | RRCC2508 | RRCC2512 | RRCC2516 | RRCC2518 | RRCC2521 | RRCC2524 | RRCC2528 | RRCC2532 |
Stent Diameter Ø (mm) | Stent length (mm) & Article number | |||||||
8 | 12 | 16 | 18 | 21 | 24 | 28 | 32 | |
Ø2.75 | RRCC2708 | RRCC2712 | RRCC2716 | RRCC2718 | RRCC2721 | RRCC2724 | RRCC2728 | RRCC2732 |
Ø3.00 | RRCC3008 | RRCC3012 | RRCC3016 | RRCC3018 | RRCC3021 | RRCC3024 | RRCC3028 | RRCC3032 |
Ø 3.50 | RRCC3508 | RRCC3512 | RRCC3516 | RRCC3518 | RRCC3521 | RRCC3524 | RRCC3528 | RRCC3532 |
Ø 4.00 | RRCC4008 | RRCC4012 | RRCC4016 | RRCC4018 | RRCC4020 | RRCC4024 | RRCC4028 | RRCC4032 |
Compliance Chart
Balloon Ø(mm) | Inflation ( | ||||||||||||||
| | NP | | | | | RBP | ||||||||
6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | |
Ø 2.00 | 1.83 | 1.87 | 1.90 | 1.93 | 1.93 | 2.00 | 2.03 | 2.06 | 2.10 | 2.13 | 2.16 | 2.20 | 2.23 | 2.26 | 2.29 |
Ø 2.25 | 2.08 | 2.11 | 2.14 | 2.18 | 2.18 | 2.25 | 2.28 | 2.31 | 2.35 | 2.38 | 2.42 | 2.45 | 2.48 | 2.52 | 2.55 |
Ø 2.50 | 2.33 | 2.36 | 2.40 | 2.43 | 2.43 | 2.50 | 2.53 | 2.57 | 2.60 | 2.64 | 2.67 | 2.70 | 2.74 | 2.77 | 2.81 |
Ø 2.75 | 2.58 | 2.61 | 2.65 | 2.68 | 2.71 | 2.75 | 2.78 | 2.81 | 2.85 | 2.88 | 2.91 | 2.94 | 2.98 | 3.01 | 3.04 |
Ø 3.00 | 2.81 | 2.85 | 2.89 | 2.92 | 2.96 | 3.00 | 3.04 | 3.07 | 3.11 | 3.15 | 3.18 | 3.22 | 3.26 | 3.29 | 3.33 |
Ø 3.50 | 3.29 | 3.34 | 3.38 | 3.42 | 3.46 | 3.50 | 3.55 | 3.59 | 3.63 | 3.67 | 3.71 | 3.76 | 3.80 | 3.84 | 3.88 |
Ø 4.00 | 3.75 | 3.80 | 3.85 | 3.90 | 3.95 | 4.00 | 4.06 | 4.11 | 4.16 | 4.21 | 4.26 | 4.31 | 4.36 | 4.41 | 4.46 |
Technical data
| Crossing Profile (Ø 2.5 mm) | 0.035’’/0.89 mm |
| Strut Thickness (Ø 2.5 mm) | 0.0027’’/68 µm (SV) |
| 0.0031’’/79 µm (MV) | |
| Metallic Surface Area | 9.1-14.9% |
| Balloon Marker Material | Platinum/ Iridium |
| Entry Profile | 0.016’’/0.41 mm |
| Proximal Shaft Diameter | 1.9 F |
| Distal Shaft Diameter | 2.7 F |
| Recommended Guide Wire | 0.014’’ |
| Guiding Catheter | Min. 5 F |
